    Cal RC

    PROPERTY SPECIFICATION
    Appearance White Powder

    Calcium carbonate

    Test List Specification
    CaCo3 >95%
    SiO2 <0.3%
    Moisture <0.4%
    Bulk Dentsity >0.46 gm/cc
    PH <9.5 +- 0.5

    Calflex-C

    Test List Specification
    Whiteness 95%
    Specific Gravity 2.56
    Average particle Size 0.04 micron
    BET Specific Surface Area 30 M2/gr
    Bulk Density 1.4 cc/gr
    Surface Coating Fatty Acid
    Chemical Analysis
    C a O 54.1%
    M g O 0.2%
    S2O3 0.2%
    S I O2 0.1%
    Ignition Loss 45.4%
    Moisture 0.8%
    PH 8.5

    dpg

    PROPERTY SPECIFICATION
    Appearance White

    Epotec YD-013

    Property Test method Unit Specification
    Epoxy Equivalent Weight ASTM D 1652-04 g/eq 820-880
    Hydrolysable chlorine ASTM D 1726-03 wt% 0.1 max
    Viscosity* @25oC (G-H) ASTM D 1545-07 O - S
    Colour* ASTM D 1544-04 Gardner 0.5 max
    Softening point ASTM D 6090-99 oC 85-98
    Insoluble TEC-AS-P-050 ppm 30 max
    Melt viscosity @ 150 oC ASTM D 4287-00 P 36-50
    *40% Solution in Butyl carbitol

    Epotec YD-128

    Property Test method Unit Specification
    Epoxy Equivalent Weight ASTM D 1652-04 g/eq 185-194
    Hydrolysable chlorine ASTM D 1726-03 wt% 0.05 max
    Viscosity* @25oC ASTM D 2196-05 cPs 11,000 - 14,000
    Colour* ASTM D 1544-04 Gardner 0.5 max
    ASTM D 1209-05 APHA -
